  1. Optical Fiber 10M 30M 50M 100M 200M 4K at 60Hz and AOC Fiber Optic HDMI cable support 18.2Gbps AOC Fiber Optic HDMI 2.0 Cable
  2. Optical Fiber 10M 30M 50M 100M 200M 4K at 60Hz and AOC Fiber Optic HDMI cable support 18.2Gbps AOC Fiber Optic HDMI 2.0 Cable
  3. Optical Fiber 10M 30M 50M 100M 200M 4K at 60Hz and AOC Fiber Optic HDMI cable support 18.2Gbps AOC Fiber Optic HDMI 2.0 Cable
  4. Optical Fiber 10M 30M 50M 100M 200M 4K at 60Hz and AOC Fiber Optic HDMI cable support 18.2Gbps AOC Fiber Optic HDMI 2.0 Cable

Optical Fiber 10M 30M 50M 100M 200M 4K at 60Hz and AOC Fiber Optic HDMI cable support 18.2Gbps AOC Fiber Optic HDMI 2.0 Cable

  • Part No. :XZCHDMI037

Optical Fiber 10M 30M 50M 100M 200M 4K at 60Hz and AOC Fiber Optic HDMI cable support 18.2Gbps AOC Fiber Optic HDMI 2.0 Cable

  1. Detailed information

Optical Fiber 10M 30M 50M 100M 200M 4K at 60Hz and AOC Fiber Optic HDMI cable support 18.2Gbps AOC Fiber Optic HDMI 2.0 Cable

DESCRIPTIONS

Our new HDMI active Fiber Optic UHD Pluggable HDMI Cable which is suited for critical and versatile installations.It supports HDMI Maximum Data Rate 18Gbps with light weight, flexible and ultra-small long-term bending radius (20mm) hybrid cable. With our advanced optical engine embedded. This HDMI Hybrid Cable provides full HDMI signal integrity, support up to 100m maximum length, plug and play. No external power required.



KEY FEATURES

1.Supports a wide range of resolutions up to 4K@60Hz (color space 4:4:4) 3D and Deep color

2.Supports Multi-channel audio, Dolby True HD, DTS-HD Master Audio

3.Is HDMI compliant: EDID, CEC, HDCP (2.2), HDR (High Dynamic Range)

4. Reduced EMI and RFI

5. Has high pulling strength  and compression load

6.Has Source / Display clearly printed on the connector as well as tagged on the cable for easy identification.

7. Support 18G super speed

8. Includes a DC cable to optionally connect an external 5V power supply(if required, this is typically connected on the display side .)

 Applications

SHDC-8800 is ideal for long distance transmission in professional AV systems, indoor and outdoor digital signage and kiosks, home theater systems, surgical theaters ,facility automation systems and whenever high resolution video and audio are required .On the display side, the micro HDMI connector enables smooth pulling of the cable. The SOURCE end connects to the source (for example, a DVD, Blu-ray or game console box) and the DISPLAY end to the acceptor (for example, a projector, an LCD display or a tablet device .

 Absolute Maximum Rating

Parameter

Symbol

Min

Max

Unit

Power Supply Voltage

VCC

4.5

5.5

V

Operating Temperature

Top

0

50

°C

Storage Temperature

Ts

-40

70

°C

Relative Humidity

Hs

10

80

%RH

 Recommended Operating Conditions

Parameter

Symbol

Min

Typical

Max

Unit

Power Supply Voltage

VCC

4.75

5.0

5.25

V

Operating Temperature

Top

0


50

°C
